详细参数请点击查看PDF文件：TJ FullMusic 300B/SE.pdf  (5.78 M)

Classification-Dome-type or Aubergine-type bulb of glass, a white ceramic base with four-prong bayonet gold pins , oxide coated filamentary, solid plate, mesh plate, cabon plate triode. Application-Audio frequency amplifier where power outputs of approximately 8.5watts or less is required at relatively low plate voltages. Dimensions-Dimensions, outline diagrams of the tube and bases, and the arrangement of electrode connections to the base terminals are shown in Figures 1, 2 and 3. Nominal operating conditions and parameters Filament voltage..........................................5 V or 2.5V Nominal filament current..........................1.2A or 2.5A Plate voltage...............................................300V Grid voltage.............................................－58 V Plate current...............................................60 mA Amplification factor....................................3.85 Grid to plate transconductance .............5.7mA/V Grid current................................................0.05 μA Plate resistance.......................................700 ohm *Alternating-current filament supply or Direct-current filament supply. **Alternating-current filament supply is used. The grid and plate returns should be connected to a center tap on the secondary of the filament transformer. ***Direct-current filament supply is used. The grid and platter returns are connected to the negative end of the filament. Characteristics-Average characteristics Figure 4. shown typical curves of plate currents of grid voltage for several values of plate voltages. It is alternating-current filament supply. Fig.4 Limiting Operation Conditions for Safe Nor-nor simultaneous ratings Maximum plate voltage.................................................................................................450 volts Maximum plate dissipation..........................................................................................40 watts Maximum plate current of average tube for fixed gird bias....................................70mA Maximum plate current of manually adjusted gird or self-biasing circuit...........100mA
